| Item code | Rated input | PF | DF | No Load power consumption | Efficiency | Output voltage | Output power range | Tolerance | Output Current | Output voltage range | Output power range | Tolerance | ta | tc | Size(LxWxH) | Approval |
| HJA6-12VF(UN)-L | AC120V | 0.60C | 0.85 | ≤0.3W | 76.6% | 12VDC | 0-6W | +/-5% | 700mA | 3-8.5VDC | 2.1-6W | +/-8% | -20...+45℃ | 85℃ | 100x44x10.8 | UL CUL |
| HJA6-24VF(UN)-L | AC120V | 0.60C | 0.85 | ≤0.3W | 78.8% | 24VDC | 0-6W | +/-5% | 350mA | 6-17VDC | 2.1-6W | +/-8% | -20...45℃ | 85℃ | 100x44x10.8 | UL CUL |
